6610 Digital Tachometer

CE Approved UK Conformity Assessed RoHS Product Video available

Non-Contact rotational measurement of speed, using photo-electric technology

  • Measuring range 2.5 - 99,999rpm (accuracy +/- 0.05%)
  • Memory: min, max, last value. Sample time 0.8sec (over 60rpm)
  • Detecting distance: 50 - 500mm
  • Size: 164 x 74 x 37mm. Supplied with a storage bag and 3 x AA batteries
  • CE, UKCA & ROHS compliant
TSP: £60.02 ex VAT £72.02 inc VAT

Non-Contact rotational measurement of speed, using photo-electric technology

  • Messbereich 2,5 U/min bis 99.999 U/min (Genauigkeit +/-0,05 %)
  • Speicher: Min/Max/Letzter Wert. Messdauer 0,8 Sek. (über 60 U/min)
  • Erfassungsabstand 50-500 mm
  • Größe 164 x 74 x 37 mm. Lieferung mit einer Aufbewahrungstasche und 3 AA-Batterien
  • CE-zertifiziert und RoHS-konform
TSP: £60.02 ex VAT £72.02 inc VAT

Mesure de la vitesse de rotation sans contact, à l'aide de la technologie photo-électrique

  • Plage de mesure 2,5 - 99 999 tr/min (précision +/- 0,05 %)
  • Mémoire : min, max, dernière valeur. Temps d'échantillonnage 0,8 s (plus de 60 tr/min)
  • Distance de détection : 50 - 500 mm
  • Dimensions : 164 x 74 x 37 mm. Fourni avec un sac de rangement et 3 piles AA
  • Conformité CE, UKCA et RoHS.
TSP: £60.02 ex VAT £72.02 inc VAT

Digitale toerenteller

  • Meetbereik 2,5 - 99.999 tpm (nauwkeurigheid +/- 0,05%)
  • Geheugen: min, max, laatste waarde. Monstertijd 0,8 sec. (boven 60 tpm)
  • Detectieafstand: 50 - 500 mm
  • Afmeting: 164 x 74 x 37 mm. Geleverd met opbergtas en 3x AA-batterijen
  • CE-, UKCA- en ROHS-conform
TSP: £60.02 ex VAT £72.02 inc VAT
CE Approved UK Conformity Assessed RoHS Product Video available
 Buy Locally

Useful Downloads
Press Release
Portable and very accurate Digital Tachometer

This new portable optical handheld tachometer from Laser Tools (part number 6610) is used for non-contact measurement of rotational speeds. Uses include maintenance and adjustment of various machines, conveyor belts, motors and belt drives, etc. It uses photoelectric, anti-jamming and junction laser technology to provide non-contact measurements over a wide range (2.5 – 99,999 RPM) and at great accuracy (± 0.05% + 1 digit).

A reflective mark is placed on the object to be measured (white reflective tape is provided for this purpose) and this is used as a target for the instrument's integral laser light beam. The detecting distance is 50-500mm, and the sample time is just .8 sec, so that the RPM is displayed on the large and clear LCD display almost instantly.

The digital tachometer has a memory function (minimum, maximum and last values) and 96 sets of continuous data can be saved. It includes a low battery indicator, and three AA batteries are included.

A professional, robust and accurate tool, it is CE certificated and ROHS compliant. Available now from your local Laser Tools supplier.
